.SHIP_COBRA_MK_1 EQUB 3 \ Max. canisters on demise = 3 EQUW 99 * 99 \ Targetable area = 99 * 99 EQUB LO(SHIP_COBRA_MK_1_EDGES - SHIP_COBRA_MK_1) \ Edges data offset (low) EQUB LO(SHIP_COBRA_MK_1_FACES - SHIP_COBRA_MK_1) \ Faces data offset (low) EQUB 69 \ Max. edge count = (69 - 1) / 4 = 17 EQUB 40 \ Gun vertex = 40 EQUB 26 \ Explosion count = 5, as (4 * n) + 6 = 26 EQUB 66 \ Number of vertices = 66 / 6 = 11 EQUB 18 \ Number of edges = 18 EQUW 75 \ Bounty = 75 EQUB 40 \ Number of faces = 40 / 4 = 10 EQUB 19 \ Visibility distance = 19 \ --- Mod: Original Acornsoft code removed: -----------> \ EQUB 90 \ Max. energy = 90 \ --- And replaced by: --------------------------------> EQUB 81 \ Max. energy = 81 \ --- End of replacement ------------------------------> EQUB 26 \ Max. speed = 26 EQUB HI(SHIP_COBRA_MK_1_EDGES - SHIP_COBRA_MK_1) \ Edges data offset (high) EQUB HI(SHIP_COBRA_MK_1_FACES - SHIP_COBRA_MK_1) \ Faces data offset (high) EQUB 2 \ Normals are scaled by = 2^2 = 4 \ --- Mod: Original Acornsoft code removed: -----------> \ EQUB %00010010 \ Laser power = 2 \ \ Missiles = 2 \ --- And replaced by: --------------------------------> EQUB %00100010 \ Laser power = 4 \ Missiles = 2 \ --- End of replacement ------------------------------> \VERTEX x, y, z, face1, face2, face3, face4, visibility VERTEX -18, -1, 50, 1, 0, 3, 2, 31 \ Vertex 0 VERTEX 18, -1, 50, 1, 0, 5, 4, 31 \ Vertex 1 VERTEX -66, 0, 7, 3, 2, 8, 8, 31 \ Vertex 2 VERTEX 66, 0, 7, 5, 4, 9, 9, 31 \ Vertex 3 VERTEX -32, 12, -38, 6, 2, 8, 7, 31 \ Vertex 4 VERTEX 32, 12, -38, 6, 4, 9, 7, 31 \ Vertex 5 VERTEX -54, -12, -38, 3, 1, 8, 7, 31 \ Vertex 6 VERTEX 54, -12, -38, 5, 1, 9, 7, 31 \ Vertex 7 VERTEX 0, 12, -6, 2, 0, 6, 4, 20 \ Vertex 8 VERTEX 0, -1, 50, 1, 0, 1, 1, 2 \ Vertex 9 VERTEX 0, -1, 60, 1, 0, 1, 1, 31 \ Vertex 10 .SHIP_COBRA_MK_1_EDGES \EDGE vertex1, vertex2, face1, face2, visibility EDGE 1, 0, 1, 0, 31 \ Edge 0 EDGE 0, 2, 3, 2, 31 \ Edge 1 EDGE 2, 6, 8, 3, 31 \ Edge 2 EDGE 6, 7, 7, 1, 31 \ Edge 3 EDGE 7, 3, 9, 5, 31 \ Edge 4 EDGE 3, 1, 5, 4, 31 \ Edge 5 EDGE 2, 4, 8, 2, 31 \ Edge 6 EDGE 4, 5, 7, 6, 31 \ Edge 7 EDGE 5, 3, 9, 4, 31 \ Edge 8 EDGE 0, 8, 2, 0, 20 \ Edge 9 EDGE 8, 1, 4, 0, 20 \ Edge 10 EDGE 4, 8, 6, 2, 16 \ Edge 11 EDGE 8, 5, 6, 4, 16 \ Edge 12 EDGE 4, 6, 8, 7, 31 \ Edge 13 EDGE 5, 7, 9, 7, 31 \ Edge 14 EDGE 0, 6, 3, 1, 20 \ Edge 15 EDGE 1, 7, 5, 1, 20 \ Edge 16 EDGE 10, 9, 1, 0, 2 \ Edge 17 .SHIP_COBRA_MK_1_FACES \FACE normal_x, normal_y, normal_z, visibility FACE 0, 41, 10, 31 \ Face 0 FACE 0, -27, 3, 31 \ Face 1 FACE -8, 46, 8, 31 \ Face 2 FACE -12, -57, 12, 31 \ Face 3 FACE 8, 46, 8, 31 \ Face 4 FACE 12, -57, 12, 31 \ Face 5 FACE 0, 49, 0, 31 \ Face 6 FACE 0, 0, -154, 31 \ Face 7 FACE -121, 111, -62, 31 \ Face 8 FACE 121, 111, -62, 31 \ Face 9Name: SHIP_COBRA_MK_1 [Show more] Type: Variable Category: Drawing ships Summary: Ship blueprint for a Cobra Mk I Deep dive: Ship blueprintsContext: See this variable in context in the source code References: This variable is used as follows: * XX21 calls SHIP_COBRA_MK_1

[X]

Variable SHIP_COBRA_MK_1 (category: Drawing ships)

Ship blueprint for a Cobra Mk I

[X]

Label SHIP_COBRA_MK_1_EDGES is local to this routine

[X]

Label SHIP_COBRA_MK_1_FACES is local to this routine
