Check all return lines from injectors, also the fuel delivery pump has two small plastic check valves, if they are not sealing it will lose it's prime.   terry:MackLogo: I suppose you should check all fuel lines!


Can someone help me identify my injector pump. The engine is a EC6-350


This is the tag on the pump


Which parts are the check valves on this schematic

Link to comment
Share on other sites

  • 1 month later...


According to the information I received from the Mack museum the passenger side power window unit shown in the photo was factory installed. This unit is on its last legs and needs to be replaced.

Does anyone know where I can get a replacement unit?

Was there originally a cover on the unit?

Link to comment
Share on other sites

You never said if the truck was hard to start both cold and warm? How does it start if allowed to set for about four hours after running?


Once started it is easy to start after 4 to 8 hours it does crank more than I like but nothing like first thing in the morning
Link to comment
Share on other sites

Right now I can't work on the truck until my knee heals from surgery last week


So right now I am planning the attack on the fuel system, looking for a source for my power window motor and a 60" sleeper

My bride was nice enough to take me to look at some cars over the weekend


  • Like 1
Link to comment
Share on other sites

14 hours ago, Quickfarms said:




There's a warranty?       There WAS a warranty.

How long is that for?        Warranty lasted until about 2 weeks before it started giving you issues.

This was my good knee



Hope the healing process goes well.

Jim

It doesn't cost anything to pay attention.

Link to comment
Share on other sites

The knee is healing and I am going stir crazy not working on my projects and dealing with my clients.

Today I installed a pressure gauge into the existing port on the secondary fuel filer that is after the lift pump.

I tried to start the truck and it cranked for a while then lit off but died

I repeated this

On the third try the batteries were getting really low so it was time to disconnect them and charge them.

So much for today, tomorrow is another day

Link to comment
Share on other sites

today I got the truck running with the pressure gauge in the secondary filter.



I ended up checking the fuel filters and the primary was 1/2 full and the secondary was about 3/4 full so I toped them off, added about 9 gallons of fuel, and it was able to be started.



The fuel pressure is about 16 psi at 800 rpm and when I increase the rpm's it goes up to about 21 psi



c80d74e27924cd60bff74908779a11e8.jpg&key=31c6f8d300e92d929a6afe9433829ea6cfe0c289eeec8f9de33c9fd087837944



When I shut the truck off it drops to zero by the time I climb down and get around to the filters



There are to visible fuel leaks any place that I can find



Any thoughts where to check now?



Several posts to this topic on or about 2/9 about this starting issue have disappeared!



Who deleted them? And why?



Link to comment
Share on other sites

Have you looked at the inlet (check) as Terry suggested above?  It is to keep the fuel primed in the system.

The author of a post can also delete them.  As to why, I don't know.


Not yet

Will a lift pump still pump if the check valves are bad?

If the check valve is bad the efficiency of the pump should be greatly reduced.

I was hoping that the fuel pressure gauge would give me some instead to the condition of the lift pump.

The nice part about this truck is that the fuel filters are readily accessible sitting on the outside of the frame


This makes it a project to get to the lift pump that is now hidden behind the fuel filters.


Looking at it it looks like the best way to get to the lift pump is to remove the fuel filters for access.

I am to the point of being frustrated and thinking about just replacing the lift pump and all of the fuel lines

Does anyone know what the PAI part number for the lift pump and rebuild kit?
