On 7/3/2025 at 10:53 PM, mowerman said:

Also according to schematics there’s supposed to be a straight head screw on the outside of end cap which holds in a release spring and two ball bearing … don’t see any screw

it should be a 5/16th  hex head set screw having a 1/2 in six point nut for lock.

In reality, that is just an adjustable "pin" that when the main gear nears the end of travel, it pushes on a ball-check valve and dumps pressure before the gear dead-heads. It doesn't hold the the head from coming off. I never touched it when doing mine, 'cause I didn't want to have to adjust it after repairs, just left it as is.

  • Like 1
