### Exponential Graph using Python

### Introduction to Exponential Graph

Exponential curve a is smooth and continues line of graph, connected by a series of co-ordinates calculated using a polynomial equation containing variable exponential value (For example, *y* = *f*(*x*), where *f*(*x*) = A*e*^{Bx} + C). In this program, I have used a polynomial equation with a exponential variable *y* = 5*e*^{-2x} + 1 with *x* values range from 0 to 10. The program generated co-ordinate points (*x*, *y*) in the graph will be (0, 6.0), (1, 1.7), (2, 1.1), (3, 1.0), (4, 1.0), (5, 1.0), (6, 1.0), (7, 1.0), (8, 1.0), (9, 1.0), and (10, 1.0).

### Program Implementation

In this tutorial, I have used Python 3.5.2 (64-bit) software, and 7 modules: MatPlotLib 2.0.2, PyParsing 2.2.0, Python-DateUtil 2.6.1, PyTZ 2017.2, SetupTools 36.2.0, Cycler 0.10.0, and NumPy-MKL 1.13.1 implemented in Windows 10 Enterprise operating system. The 7 modules are chosen based on the compatibility of Python and OS version and bit.

#### Source Code

```
import numpy as np
import matplotlib.pyplot as plt
a = 5
b = 2
c = 1
x = np.linspace(0, 10, 256, endpoint = True)
y = (a * np.exp(-b*x)) + c
plt.plot(x, y, '-r', label=r'$y = 5e^{-2x} + 1$')
axes = plt.gca()
axes.set_xlim([x.min(), x.max()])
axes.set_ylim([y.min(), y.max()])
plt.xlabel('x')
plt.ylabel('y')
plt.title('Exponential Curve')
plt.legend(loc='upper left')
plt.show()
```
